Multi tasking CNC Lathe OKUMA MULTUS B400-W1500

OSP-P200L φ710×1500  Main KITAGAWA B-210 hollow chuck 3800rpm 22Kw   Sub KITAGAWA B-210 hollow chuck 3800rpm 22Kw   Bore: φ80 H1-ATC t…

T-slot Surface Plate 2500×1000

T : 2500×1000

Polyarticular robot FANUC M-16i

R-J2 Load Capacity16kg

Inverter Spot welding machine AMADA ID-40-ST

Rated capacity:40kva   Inverter type resistance welding controller   (DIT-6020-1-A)  Circulating water cooling system(CU4002)  Elevating…

Multi tasking CNC Lathe MAZAK INTEGREX J-300

Matrix NEXUS-2 φ640×1026  KITAGAWA 12inch hydraulic chuck B212A815  4000rpm AC18.5Kw Bore:φ91 ATC-36 Tool eye  Spindle index:0.0001 MILL …

Compressor HITACHI OSP-37VARN

37kw  3-phase 200V(50Hz)/200・220V(60Hz) 0.7MPa  Air Volume: 6.6㎥/min  Inverter・Built-in dryer  Air dryer:Refrigerant gas filling (2022/12…

Compressor HOKUETSU SMS15ERD-5E

0.7MPa 15kw 50hz 550kg

CNC Profile Grinder WASHINO GLS-680H

F-16M 0.0001mm T:300×250  Table stroke:Z-200 V-135 Elevator-100  Spindle stock:X-170 Y-100 Rotate-±10  Platform:0~80mm 30~80spm   Wheel:…

CNC Surface Grinder OKAMOTO PSG-158DXNC

F-32i MG chuck:1500×800  X-1750 Y-860 Z-720  Wheel:φ510×50×φ127 700~1500rpm 15Kw  Wheel continuously variable transmission  Oil cool…

Wire Cut FANUC α-1iC

F-180iS-WB Max work size:820×730×300  X-550 Y-370 Z-310 U-±60 V-±60   Taper:±30°/80 Wire:φ0.1~0.3  Load:1000kg

DIE Spotting Press SANKI SDP-1310-100T

100ton 180 ° inversion type  Table:1300×1000 OH:1200mm   Stroke:1130mm Lifting capacity:39t  Mold capacity:6t Inverted angle:0~180°  Tr…

CNC Surface Grinder OKAMOTO PSG-158DXNC

F-32i MG chuck:1500×800  X-1750 Y-860 Z-720  Wheel:φ510×50×φ127 700~1500rpm 15Kw  Wheel continuously variable transmission  Oil cool…

5axis Multi Machining-center MAZAK INTEGREXe-1850V

Fusion 640M Pro  T:φ1850 4jaw chuck & □1250×2APC ATC-80  Work capacity: φ2350×1800h  X-3055 Y-1850 Z-1800 B-150°(30~+120°)   B-±360 B-0.…

Vertical Lathe TOSHIBA TD-40/ 65S

φ6500 T:φ4000 4jaw chuck  0.8~40rpm(18steps) AC75Kw(Invertor)   Table load:50t Rotation force: 16t・m   Table to under cross rail: 4000mm …

T-slot Surface Plate 2500×650 (960702KUN-1-2)

T:2500×650 With stand

Multi tasking CNC Lathe MAZAK INTEGREX 400-Ⅲ

Mazatrol 640MT Pro φ760×1034    KITAGAWA N-15 hydraulic chuck Crossφ660  X-630 Y-230 Z-1095 Bore: φ112  Spindle index:0.0001° ATC-20   C…

CNC Vertical Turning-center OKUMA VTM-200

Control device:OSP-P200LA   RAKURAKU Advanced L composite LAP-4  φ2400×1200h  φ2000 placed jaw chuck 5~200rpm 30Kw  S: X-1600  Z-1200  C…

Surface Grinder OKAMOTO PSG-208B

MG chuck 2000×800 Wheelφ510×50×φ127   980rpm 7.5Kw Left right 2150×Front back 830mm   Table~under wheel 695mm Overhead wheel dresser  Pap…

Surface Grinder OKAMOTO PSG-208B

MG chuck 2000×800 Wheelφ510×50×φ127   980rpm 7.5Kw Left right 2150×Front back 830mm   Table~under wheel 695mm Overhead wheel dresser  …

Semi-Automatic Welding Machine PANASONIC YD-180R-2

With wire feeder (YM-358UFH K8)

T-slot Surface Plate 2500×650 (960702KUN-2-2)

T : 2500×650

T-slot Surface Plate 2000×800×100

T: 2000×800×100 (above floor level 880)  With stand

4t Forklift TOYOTA 7FGK40

4t Maximum lifting height: 3m   Gasoline No puncture tire

comingsoon

Ultrasonic Washing Machines HONDA WT-120-40

External Dimensions:800×460×477  Internal dimensions:610×400×300(63L)SUS  1200W AC200V

comingsoon

Ultra precision surface plate FUJIOKA 2000×1000

2000×1000×280   Surface plate for precision inspection

5axis Machining-center MAZAK VARIAXIS I-800

Smooth X T:□500×2APC ATC-40  Work capacity:φ730×500 Table load:500kg  X-730 Y-850 Z-560 A--120~+30°  C-360°  10,000rpm BBT-50 AC30Kw(…

Outside Micrometer MITUTOYO OM-150(930920KIY-60)

125〜150mm

Outside Micrometer MITUTOYO OM-100 (851207YOS3-17-2)

75~100mm

Auto Circular Saw TSUNE TK5M-90PL

Full auto  Capacity:φ10~90mm □10~70mm   Cutting range:5~200mm Material length:1.6~4.2m   Blade: Hybrid Saw φ250~330×2t   514~1234rpm 7.5K…

Mist collector kuraco ASST-202

Surface Grinder OKAMOTO PSG-126DX

FX control MG chuck φ1200×600   Wheel:φ510×50×127 Motor horsepower UP 11kw  Unauthorized gearbox Oil cooler  Upper dresser   Full auto  U…

Surface Grinder OKAMOTO PSG-52BN

MG chuck:550×200 Wheel:φ205×19×φ50.8   3000rpm 1.5kw

Surface Grinder NAGASHIMA NAS-520F

MG cuck:500×200 Coolant tank  Wheel:φ255×25×φ50.8 3600rpm 3.7kw  3axis digital scale

Radial Drill OKUMA DRA-J1600

Bore:φ70(steel) 14~1800rpm MT-5  Base~Spindle ends:300~1485mm  Spindle:400 5.5Kw

Vertical Lathe OM TMS2-20/55

φ5500 Table:φ2000+φ4000  Work height:1600mm Ram tilt:30°  Table load:20t   Rotation force:4000Kg・m  Cutting force:3000Kg Bite:□40mm  Ma…

Vertical Lathe OM TMS2-20/55

φ5500 Boring Mill Jaws  Table:φ2000  Work height:1600mm Ram tilt:30°  Table load:20t   Rotation force:4000Kg・m  Cutting force:3000Kg Bi…

Form Grinder OKAMOTO PFG-500Ⅱ

T: 600×140 MG:380×110×130  Wheel : φ180*6-32*φ31.75  Wheel motor : 1.5kw  YZ axis digital scale(Forward and backward・up and down)  Coola…

Form Grinder MITSUI MSG-205M

T:480×160  Table~Wheel axial core:450mm  Wheel:φ205×20×31.75mm 2900rpm  Electric Motor:1.0kW/2P V-3  Power Supply:3 phase 200V  Power Su…

Form Grinder NICCO NFG-515

T:380×110㎜ Wheel φ180×6~32×31.75㎜  With vertical feed 2axis digital scale   Bite grind system・Coolant tank

CNC Cylindrical Grinder TOYODA GL4P-50

GC32 φ320×500 Workpiece weight: 150Kg  Grinding wheel φ405×100×φ127 Spindle: 2120rpm   Spindle stand・tailstock::MT-4   Work spindle stand…

RADIAL DRILL OGAWA HOR-1500

Bore:φ55 30~1500rpm MT-5 3.7kw  Column ~ Spindle center : 345~1525mm  Spindle end ~ Base surface : 365~1430mm

RADIAL DRILL OOYA RE2-1450

Bore:φ52  32~1655rpm MT-5 3.7kW  Spindle:300  Distance from base to spindle:330~1315mm

Cylindrical Grinder RANDIS- Nippei 4RPL-24×120

φ646×2851mm Between center:3048mm  Wheel:φ610×150×φ304.8 1080rpm  Work weight:1350Kg   Work head:MT-5+A1-6 dead & live  3Jaw chuck  Tail…

CNC Vertical Turning-center OKUMA HOWA VLM-100

FANUC-18T φ1000×840   3 jaw scroll chuck φ800 APC-12  4~1250rpm 30Kw Torque: 2580Nm   X-650 Z-840 C-0.001°  Mill:4500rpm 7.5Kw ATC-36  …

Full HD Microscope With Built In Measurement Function Shodensha TG200HD2-Me

Magnification 30x-180x  Working distance 90mm  Field of view 12.0mm×6.7mm (during 30x) 2.0mmx1.1mm (during 180x)  Image Sensor 1/3”CMOS  …

BAND SAW AMADA H-1080 (1300W)

Capacity:φ1000 □1300×1000h   Hydraulic vise Moving vise stroke 400mm  Table load:15 ton  Saw blade:80×1.6×10,100   13~75 m/min Variable …

Vertical Machining Center MAZAK VCN410BⅡ HS

MX-NEXUS T:1100×410 X-762 Y-410 Z-510 ATC-30  Table~Spindle: 660mm  18000rpm BT40 AC30Kw(40HP)  X/Y/Z axis ball screw axis center cooling…

Vertical Machining-center MAKINO V-77

Professional-5  ATC-20  T:1400x700 Pallet: 1250×630×2APC  X-1200 Y-700 Z-650 High column-200㎜  50~12000rpm BBT-50 AC22Kw   More less sc…

RADIAL DRILL Malmec TPR-820A

Arm:820 88~1500rpm MT-4 1.5Kw

Turret Milling MAKINO KVP-55

T:1100×250 250~4000rpm NT-40  X-550 Y-250 Z-350 Qiill-100  3 axis digital
